21.5″ Floor Stand Kiosk
Physical Dimension
|
Screen |
21.5 inch |
|
Display area |
478 * 269.5 mm (16:9) |
|
Machine dimension(W×H×T) |
342.6(W)×1720(H)×36.8(T)mm |
|
Packing dimension(W×H×T) |
480(W)×1460(H)×23.5(T)mm |
|
N.W |
23.7 KG |
|
G.W |
32.5 KG |
LED Panel Parameters
|
LED panel(a-Si TFT-LCD WLED backlight)A type |
|||
|
Size |
32 inch (16:9) |
||
|
Display area |
698.7*393.3 mm (16:9) |
||
|
Max. resolution |
1920*1080P |
||
|
Brightness |
≥250cd/m2 |
Aspect ratio |
≥ 1000:1 |
|
Response time |
14(Typ.)(Tr/Td) ms |
Refresh frequency |
60Hz |
|
No. Of colors |
16.7M , 52% (CIE1931) LVDS ports 30 Pins |
||
|
Angle of viewing |
Full viewing 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
||
|
Lifetime |
Min:30000H; |
||
2.4 Electrical Performance
|
Input power |
110-240V AC 50/60Hz |
||
|
Monitor consumption |
60 W |
Standby consumption |
0.5 W |
|
Android consumption |
65 W |
Speaker power |
8Ω5w |
|
X86 consumption |
95 W |
||
2.5 Working Environment
|
Working temperature |
-10℃–60℃ |
|
Working humidity |
0% – 90% |
|
Storage temperature |
0℃-60℃ |
|
Storage humidity |
0% – 65% |
Touch monitor interfaces
|
2.1mm DC12V*1 |
Audio |
1 |
|
|
VGA input (15pin D-Sub) |
1 |
HDM input |
1 |
|
USB touch interface |
1 |
||
Android AIO interfaces
|
Power cord |
2.1mm DC12V*1 |
Headphone |
1 |
|
RJ45 |
1 |
HDM |
1 |
|
USB (with OTG) |
2 |
WIFI antenna |
1 |
|
TF /SD card slot |
1 |
TTL/232/485 serial options |
|
Windows AIO interfaces
|
Power cord |
2.5mm DC12V*1 |
Headphone |
1 |
|
RJ45 |
1 |
HDM |
1 |
|
USB (with OTG) |
4 |
WIFI antenna |
1 |
|
TF /SD card slot |
1 |
232/485 serial options (2 to 6 ports) |
|
