Products Description
|
Model
|
FSA7-3
|
|||||
|
For
|
Europe
|
North America
|
||||
|
Power Input
|
Input Type
|
1-Phase
|
3-Phase
|
1-Phase
|
||
|
|
Input Wiring Scheme
|
1P+N+PE
|
3P+N+PE
|
1P+N+PE
|
||
|
Power Input
|
Rated Voltage
|
230VAC±10%
|
400VAC±10%
|
L1:100VAC±10%/ L2:230VAC±10%
|
||
|
Rated Current
|
16A or 32A
|
|||||
|
Grid Frequency
|
50HZ or 60HZ
|
|||||
|
Power Output
|
Output Voltage
|
230VAC±10%
|
400VAC±10%
|
L1:100VAC±10%/ L2:230VAC±10%
|
||
|
Maximum Current
|
16A or 32A
|
|||||
|
Rated Power
|
7KW
|
11KW or 22KW
|
3.5KW/7kW
|
|||
|
User Interface
|
Charge Connector
|
Type 2 Plug
|
Type 1 Plug
|
|||
|
Cable Length
|
5m or Optional
|
|||||
|
LED Indicator
|
Green/Blue/Red
|
|||||
|
LCD Display
|
4.3 Inch Touch Color Screen(Optional)
|
|||||
|
RFID Reader
|
ISO/IEC 14443 RFID Card Reader
|
|||||
|
Start Mode
|
Plug&Charge/RFID Card/APP
|
|||||
|
Communication
|
Backend
|
Wi-Fi /Cellular(Optional) / Ethernet(Optional)
|
||||
|
Charging protocol
|
OCPP-1.6J
|
|||||
|
Safety and
Certification
|
Energy Metering
|
Embedded Meter Circuit Component With 1% accuracy
|
||||
|
Residual Current Device
|
DC 6mA+Type A AC 30mA
|
|||||
|
Ingress Protection
|
IP55
|
|||||
|
Impact Protection
|
IK10
|
|||||
|
Cooling method
|
Natural Cooling
|
|||||
|
Electrical Protection
|
Over/Under Voltage Protection,Over Current Protection, Short Circuit protection,
Over/Under Temperature Protection,Lightning Protection,Ground Protection |
|||||
|
Certification
|
CE
|
|||||
|
Certification and Conformity
|
IEC61851-1,IEC62196-1/-2,SAE J1772
|
|||||
|
Environment
|
Mounting
|
Wall-mount/Pole-mount
|
||||
|
Storage Temperature
|
-40℃ – +85℃
|
|||||
|
Operating Temperature
|
-30℃ – +50℃
|
|||||
|
Max.Operating Humidity
|
95%，Non-condensing
|
|||||
|
Max.Operating Altitude
|
2000m
|
|||||
|
Mechanical
|
Product Dimension
|
270mm*135mm*365mm（W*D*H）
|
||||
|
Package Dimension
|
325mm*260mm*500mm（W*D*H）
|
|||||
|
Weight
|
5kg(Net ) / 6kg(Gross)
|
|||||
|
Accessory
|
Cable Holder,Pedestal(Optional)
|
|||||
