Product Description
|
Model
|
YHEVP-01
|
||
|
AC Nominal Input
|
Phases / Lines
|
1 Phase + Neutral + PE
|
|
|
Voltage
|
230 V± 10%
|
||
|
Frequency
|
50Hz
|
||
|
AC Nominal Output
|
Voltage
|
230 V± 10%
|
|
|
Current
|
16A
|
||
|
Power
|
3KW
|
||
|
Structure Design
|
Display Screen
|
LED display
|
|
|
LED Indicator
|
4 indicators
|
||
|
Power Cord Plug
|
UK / US / Schuko/ CEE / Nema（Optional）
|
||
|
Charging Outlet
|
J1772(Type 1)
|
||
|
Plug Cable Length
|
0.5M
|
||
|
Gun Cable Length
|
4.5M
|
||
|
Housing Material
|
PC
|
||
|
Environmental
|
Operating Temperature
|
-30 ~ +50 °C
|
|
|
Working Humidity
|
5%~95% Without condensation
|
||
|
Working Altitude
|
<2000M
|
||
|
Index
|
Protection Grade
|
IP665
|
|
|
Application Site
|
Indoor / Outdoor
|
||
|
Cooling Method
|
Natural cooling
|
||
|
Security Protection
|
Multiple Protection
|
Over/Under voltage protection,
Over/Under frequency protection,
Over/Under temperature protection,
Over current protection,
Current leakage protection, Grounding protection |
|
|
MTBF
|
50,000 hours
|
||
|
Safety Standard
|
SAE J1772-2010
|
||
|
Warranty
|
1 years
|
||
|
Package Information
|
Product Dimension
|
21*9*5cm
|
|
|
Package Dimension
|
35*32*6cm
|
||
|
Net Weight
|
2.5KG
|
||
|
Gross Weight
|
3KG
|
||
|
External Packing
|
Carrying case + Carton box
|
||
Shinging Technology Co.,Ltd. was founded in 2008 and located in Shanghai, China,specialized in researching, manufacturing and selling EV charger product.We focuse on the R&D and manufacturing of auto- motive precision parts and EV charging products like plugs, sockets, charging connectors,portable ev chargers and charging cables.Our factory building area covering 22,585 square meters, with 13 production lines.We have optical electronic laboratories, advanced professional test equipment. Our products have passed the EU TUV CE certification, U.S. UL certification, and exported to Europe,North America, Southeast Asia and other regions. We can accept OEM&ODM orders also. Welcome to contact with us.
